Resonant Circuit Capacitor

TOPEN TOPProductsResonant Circuit Capacitor

Characteristics

  • High pulse resistant
  • Low loss, high insulation resistant

Applications

  • For resonant circuits in automatic transporters, EV wireless power supply, induction cookers, etc.

Dimensions

Dimension of resonant circuit capacitor

Electrical characteristics (reference specifications)

You can see the whole table by scrolling.

Item Basic Specifications
Rated voltage 600Vac @10kHz~100kHz
Capacitance *1 2.0µF±5% 4.0µF±5%
Permissible current *2 50Arms 60Arms

*1: 0.1~1.5µF under development　*2: Self-heating10°C or less

Applications (wireless power transfer)

Wireless charging device
Resonant circuit coil

The content may change without notice. Please refer to our specification sheet before ordering.
